<7. Troubleshooting>
7-3
IM 11B08A01-01E
7.1.4 Alarm Contents
The alarm type and contents are as the following tables.
In the alarm display, possible causes and corrective actions are shown. Fix the problems
referring to them.
The thresholds to activate alarms are shown in the table below.
D/I alarm of level 2 and 3 are set from the D/I Setup Screen in EtherLCD.
 Level 1
 Fixed Alarm
No. MESSAGE Alarm Contents Threshold Item Threshold Threshold
Setting
1 SYS ERR System error Launch task
Send message
Other
Error to launch task
Error to send
message, etc
N/A
2 OVEN 1 SYS ERR Oven 1 system error
3 OVEN 2 SYS ERR Oven 2 system error
4 OVEN 3 SYS ERR Oven 3 system error
14 DATABASE INIT
ERR
Database init error Initialize DB Error to initialize DB N/A
15 CONC CALC ERR Conc calc error Calculation time Calculation was not
concluded before
the start of the next
analysis
Method setting
screen
16 OVEN1 INIT ERR Oven1 init error Launch task
Send message
Other – initialize DB
Error to launch task
Error to send
message
Error to initialize DB
N/A
17 OVEN2 INIT ERR Oven2 init error
18 OVEN3 INIT ERR Oven3 init error
26 FILE INIT ERR File initialization error Initialize File system Error to initialize File
system
N/A
27 ETHER INIT ERR Ethernet initialization
error
Initialize Ethernet Error to initialize
Ethernet
N/A
28 FTP INIT ERR FTP initialization
error
Initialize FTP Error to Initialize FTP
31 CTL CARD ID ERR Card ID error System setting Mismatch between
system setting and
card ID
Slot setting
32 OVEN1 CARD ID
ERR
Oven card 1 ID error System setting Mismatch in
isothermal and
programmed
temperature settings,
and explosionproof
requirements
N/A
33 OVEN2 CARD ID
ERR
Oven card 2 ID error
34 OVEN3 CARD ID
ERR
Oven card 3 ID error
35 TMP CARD1 ID ERR Temp. card 1 ID error System setting Mismatch in
card marks and
explosionproof types
N/A
36 TMP CARD2 ID ERR Temp. card 2 ID error
37 TMP CARD3 ID ERR Temp. card 3 ID error
38 DET CARD1 ID ERR Detector card 1 ID
error
System setting Mismatch in card
types
Detector setting
39 DET CARD2 ID ERR Detector card 2 ID
error
40 DET CARD3 ID ERR Detector card 3 ID
error
52 DET1-1 FPGA ERR Detector card 1-1
FPGA error
Write software in
FPGA
Error to write
software in FPGA
N/A
53 DET1-2 FPGA ERR Detector card 1-2
FPGA error
54 DET2-1 FPGA ERR Detector card 2-1
FPGA error
55 DET2-2 FPGA ERR Detector card 2-2
FPGA error
56 DET3-1 FPGA ERR Detector card 3-1
FPGA error
57 DET3-2 FPGA ERR Detector card 3-2
FPGA error
2nd Edition : May 11, 2012-00
