<5. EtherLCD>
5-33
IM 11B08A01-01E
5.3.9 Detector Adjustment
 Detector type: TCD - Reset screen
1 1 / 1 1 / 2 2
1 5 : 1 5 : 4 5 Det Adjustment
Oven # 1 Det # 1 ( TCD )
> - Det operation Off
- Reset status Initialized
Menu Adjust Reset Oven# Det#
F1 F2 F3 F4 F5 F6
Figure 5.44 Example of the detector type: TCD - reset screen
F1 (Menu): Displays the Table Menu screen.
F2 (Adjust): Displays the Det Adjustment (Execution) screen.
F4 (Reset): Initializes voltage values.
Pressing F4 displays the options Abort and Initialize. If the Set/Ent key is
pressed after the selection of Initialize, the TCD voltage value is set to its
minimum value 5.0 V.
F5 (Oven #): Sets an oven number.
F6 (Det #):
Sets a detector number.
• The TCD voltage value is read at a one-second interval, when, if the value is 0.0 V, the
status is refreshed with Initialized; otherwise Setting done.
• The Det operation is refreshed at a one-second interval.
• The numbers of ovens to which no detectors are installed cannot be set via F5.
Display Item Name Set Lower Limit Upper Limit Unit Remarks
Oven # Oven number 1 3
Det # Detector number 1 2
Detector type TCD
Det operation ○ 0: Off
1: On
* For this operation, the user
level C or higher is required and
the operation mode must be
Stop in Manual status.
Reset status ○ 0: Initialized
1: Setting done
* If the voltage value is
zero, Initialized is displayed;
otherwise Setting done.
2nd Edition : May 11, 2012-00
