<4. GC-HMI (touch panel)>
4-26
IM 11B08A01-01E
F0429.ai
Press this icon.
Figure 4.29
Example of Analyzer Operation Screen
4.4.1 GCM
Tab
The GCM tab displays information about the active GCM.
Screen components are as shown below.
F0430.ai
(C) GCM operating status
display area
Tab
(A) GCM general information display area
(B) Elapsed time bar indicator
Figure 4.30
GCM Tab Layout
(A) GCM general information display area
This area displays general information about GCM.
2nd Edition : May 11, 2012-00
