<5. EtherLCD>
5-6
IM 11B08A01-01E
5.2.2 A/O Status
To display the Analog Output (A/O) status, move the cursor (>) with or to the A/O Status
row and press .
1 1 / 1 1 / 2 2
1 5 : 1 5 : 4 5 A/O Status
Slot # 1
AO# Output item
Value
1 Det 1-1 AO Chromatogram 0.000
2 - - - - - - - - - - - - - - - - - - - - - - - - - - 0.000
3 - - - - - - - - - - - - - - - - - - - - - - - - - - 0.000
4 - - - - - - - - - - - - - - - - - - - - - - - - - - 0.000
5 - - - - - - - - - - - - - - - - - - - - - - - - - - 0.000
6 - - - - - - - - - - - - - - - - - - - - - - - - - - 0.000
7 - - - - - - - - - - - - - - - - - - - - - - - - - - 0.000
8 - - - - - - - - - - - - - - - - - - - - - - - - - - 0.000
Menu Table Slot#
F1 F2 F3 F4 F5 F6
Figure 5.6 Example of the A/O status screen
F1 (Menu): Displays the Status Menu screen.
F4 (Table): Displays the A/O Setup screen.
F6 (Slot #): Sets a slot number (applicable only when multiple analog output cards are
inserted).
TIP
• The Value data are refreshed automatically at a fi xed interval (1 second).
• On the initial screen, the smallest slot number among those of the A/O cards inserted is displayed.
• For the slot number setting, only slot numbers of A/O cards can be accepted.
If no A/O cards are inserted, the Status Menu screen displays “Not load” on the bottom.
Display Item Name Set Lower Limit Upper Limit Unit Remarks
Slot # Slot number 1 5 Absolute slot number
AO # A/O channel number 1 8 Relative channel number
Stream number on
the output
1 31
Peak number on the
output
1 999 Relative peak number
Output item A/O output peak
name
8 single-byte alphanumeric
characters
Analysis results on
the output
0.000
0.000
999.999
9999.999
When the unit is %
For other units
* The number of effective digits
is 6.
Analysis value unit
on the output
See the Measuring unit of the
Peak Setup-Specifi c screen.
* Only the upper 5 characters
are displayed.
Detector number None, 1-1, 1-2, 2-1, 2-2, 3-1, 3-2
* Oven number and relative
detector number
Value A/O value -0.25 1.25 If the value stored in the
database is 10000, it is shown
as 1.0000.
