<5. EtherLCD>
5-74
IM 11B08A01-01E
Display Item Name Set Lower Limit Upper Limit Unit Remarks
GCM #
Cal (Val)
method
○ Manual, Semi-auto, Auto
Auto start
date
○ 2000 to 2099, Jan to Dec, 1st
to 31st*
* Upper Limit will differ
depending on the month
Auto start
time
○ 0 to 23 hours, 0 to 59 minutes
Time interval ○ 0 to 255 days, 0 to 23 hours, 0
to 59 minutes
Date, Hour, and Min cannot be
set to all 0.
Auto cal
status
Stopping, Executing
 Calibration set
Press F4 (Cal).
1 1 / 1 1 / 2 2
1 5 : 1 5 : 4 5 Calibration Setup
GCM # 1 Cal # 1
> - Cal stream 2
- Cal times 1
- Auto cal Unexecuted
- ValStr# before Cal 0
- ValStr# after Cal 0
- Val before Cal times 1
- Val after Cal times 1
Menu Peak Main GCM# Cal#
F1 F2 F3 F4 F5 F6
Figure 5.82 Example of calibration set screen
F1 (Menu): Displays the Table Menu screen.
F2 (Peak): Displays the calibration peak set screen.
F4(Main): Displays the Cal/Val Set (main) screen.
F5 (GCM #): Specifi es a GCM number.
F6 (Cal #):
Specifi es a Cal number.
When ValStr # before Cal and ValStr # after Cal are set to 0, Val stream is not executed.
• When a GCM number is changed, the Cal number is allowed to return to 1.
• A Cal stream can be set to Cal only when a stream type is set to Cal. When the setting is
attempted with a stream type other than Cal, the message “The kind of stream is incorrect”
is displayed. When it does not exist in the relevant GCM, the message “The stream doesn’t
exist in GCM” is displayed.
• A ValStr # before Cal and a ValStr # after Cal can only be set when the stream type is Val.
When the stream type is other than Val, the message “The kind of stream is incorrect” is
displayed. When it does not exist in the relevant GCM, the message “The stream doesn’t
exist in GCM” is displayed.
