<5. EtherLCD>
5-99
IM 11B08A01-01E
Display Item Name Set Lower Limit Upper Limit Unit Remarks
GCM # GCM Number
Temp Unit ○ 0) °C
1) Fahrenheit (Refer to SI unit
limitation)
Det number of
SIMDISM
○ 0) NA
1) 1-1
2) 1-2
3) 2-1
4) 2-2
5) 3-1
6) 3-2
Only detectors assigned to
relevant GCM can be set up.
Response factor
updating
○ Not done, Done
Section updating ○ Not done, Done
Calilb curve
updating
○ Not done, Done
 SimDis Calib Data Setup
Press F4 (Curve).
1 1 / 1 1 / 2 2
1 5 : 1 5 : 4 5 SimDis Calib Data Setup (1/3) 1 1 / 1 1 / 2 2
1 5 : 1 5 : 4 5 SimDis Calib Data Setup (2/3)
GCM # 1 / SYS # 1 / Method # 1 GCM # 1 / SYS # 1 / Method # 1
> - Data acquisition str 0 > - Data acquisition peak3 0
- Calib curve coef a 1.000 - Elapsed time 3 0.0 s
- Calib curve coef b 1.000 - Std B.P 3 0.0
- Data acquisition peak1 0 - Data acquisition peak4 0
- Elapsed time 1 0.0 s - Elapsed time 4 0.0 s
- Std B.P 1 0.0 - Std B.P 4 0.0
- Data acquisition peak2 0 - Data acquisition peak5 0
- Elapsed time 2 0.0 s - Elapsed time 5 0.0 s
- Std B.P 2 0.0 - Std B.P 5 0.0
Menu SYS# Method# Menu SYS# Method#
F1 F2 F3 F4 F5 F6 F1 F2 F3 F4 F5 F6
Figure 5.112 Example of SimDis Calib Data Set (1/3) screen
F1 (Dist): Displays the SimDis Setup screen.
F5 (SYS #): Specifi es a SYS number.
When F5 (SYS #) is pressed, “SYS No.:” is displayed on the second line below. Use the numeric
keypad to enter the number and press the SET/ENT key, and a cursor jumps to the SYS number.
Only the SYS numbers set in GCM is selectable. When any other number is entered, “Over limit”
is displayed on the second line below.
• F6 (Method #): Specifi es a Method number.
• The GCM number displayed on the second line above is the same as the one set on the
SimDis Setup screen.
• Data acquisition streamSet the cal run stream number acquired for acquiring data to
compile a SimDis calib curve. On the stream setup screen, when a stream number with
other stream type than Cal run is about to be set, the error message “No cal run stream” is
displayed on the second line below.
• Calib curve coef a & b
Linear ramp a & slice b of a SimDis Calib curve. Auto updating and manual entry are
possible.
