<4. GC-HMI (touch panel)>
4-22
IM 11B08A01-01E
Figure 4.23 Changing the Active GCM
(3) GCM2 has been made active. This is indicated as the background of the GCM2 line turns
blue and the active GCM number on the caption banner shows GCM2.
 Changing the operating mode
TIP
This operation is available if the user level is set to B or higher. The forced stop function is enabled only for user
level C+.
The operating mode can be changed separately for each GCM, or for all GCMs at once.
 To change the operating mode of each GCM
Press the operating status change button for the desired GCM.
The screen displays the operating status change dialog for GCM1.
