Yokogawa GC8000 Process Gas Chromatograph - Manual (Page 534)

App.H-17
IM 11B08A01-01E
Setting description Setting range Initial value Accuracy
Current time set Date 1 to 31 1 None
Hour 0 to 23 12
Minute 0 to 59 0
Assign peak num
set
Stream#01 to 31 Assign
peak num
0 to 999 0 The upper limit of the total assigned
peak numbers of all streams is 999.
Peak conc set Peak#001 to 999 conc 0.000 to
9999.999
0.000 Three decimal places, signifi cant
number of digits ≤ 7
Peak keep time
set
Peak#001 to 999 rt 0.0 to 21600.0 0.0 One decimal place, signifi cant
number of digits ≤ 7
Peak area set Peak#001 to 999 area 0.000 to
9999.999
0.000 Three decimal places, signifi cant
number of digits ≤ 7
Peak heigh set Peak#001 to 999 height -1000.000 to
1000.000
0.000 Three decimal places, signifi cant
number of digits ≤ 7
Peak start time
set
Peak#001 to 999 start time 0.0 to 21600.0 0.0 Three decimal places, signifi cant
number of digits ≤ 7
Peak start height
set
Peak#001 to 999 start
height
-1000.000 to
1000.000
0.000 Three decimal places, signifi cant
number of digits ≤ 7
Peak end time set Peak#001 to 999 end time 0.0 to 21600.0 0.0 One decimal place, signifi cant
number of digits ≤ 7
Peak end height
set
Peak#001 to 999 end
height
-1000.000 to
1000.000
0.000 Three decimal places, signifi cant
number of digits ≤ 7
Table 3 Description of the GCM Status Window
Setting description Indication Initial value
GCM run GCM1 to 6 run ON, OFF OFF
GCM stop GCM1 to 6 stop ON, OFF OFF
GSM pause GCM1 to 6 pause ON, OFF OFF
DO on DO01 to 25 on ON, OFF OFF
DO off DO01 to 25 off ON, OFF OFF
Peak range Peak#001 to 999 range 0 to 31 0
GCM calibration/validation GCM1 calibration 1 to 6, GCM1 validation 1 to 6
to
GCM6 calibration 1 to 6, GCM6 validation 1 to 6
ON, OFF OFF
GCM stream sequence GCM1 to 6 stream sequence no 1 to 8 0
GCM stream specify GCM1 to 6 stream no specify 1 to 31 0
GCM stream repeat specify GCM1 to 6 stream repeat num specify 0 to 999 0
Peak update conc Peak#001 to 999 updated conc 0.000 to 9999.999 0.000
2nd Edition : May 11, 2012-00
App.H
