<5. EtherLCD>
5-101
IM 11B08A01-01E
5.4.27 MODBUS CLIENT Setup
1 1 / 1 1 / 2 2
1 5 : 1 5 : 4 5 MODBUS CLIENT setup
MODBUS # 1
>
- IP address 0.0.0.0
- Flag Disconnect
Menu MODBUS#
F1 F2 F3 F4 F5 F6
Figure 5.114 Example of MODBUS Client Setup screen
F1 (Menu): Displays the Table menu screen.
F6 (MODBUS): Sets a MODBUS number.
Up to 20 GCs which enable communication between GC are able to be registered on the LCD
screen. The procedure is as follows.
1. Press F6 (Modbus #), and the setup screen is selected.
2. Set the IP address of the GC of the connection destination and change the fl ag to Connect.
Note: While the GC of the connection destination remains Connect, it cannot be re-registered on another setup screen. A message
advising that the same GC cannot be registered is displayed.
Display Item Name Set Lower Limit Upper Limit Unit Remarks
MODBUS # MODBUS Number 1 20
IP address ○ *
Flag ○ * Disconnect, Connect
*: The settings are valid after rebooting or turning off/on its power.
2nd Edition : May 11, 2012-00
