Operating Parameters
(7/8)
>
- SV air press
- Elec Purge press
Menu
F1
F2
F3
F4
F5
F6
Figure 5.59
Example of the operating parameters screen (7/8)
F1 (Menu):
Displays the Table Menu screen.
Display Item
Name
Set Lower Limit Upper Limit
Unit
Remarks
SV air press
○
Alpanumeric: 18 characters
Elec purge
press
○
Alpanumeric: 18 characters
1 1 / 1 1 / 2 2
1 5 : 1 5 : 4 5
Operating Parameters
(8/8)
Oven # 1
>
- Oven air Press
- TPM Vortex press * * * * * * * * * * * * * * * * * *
- FPD Vortex press
Menu
Oven#
F1
F2
F3
F4
F5
F6
Figure 5.60
Example of the operating parameters screen (8/8)
F1 (Menu):
Displays the Table Menu screen.
F6 (Oven #): Selects an oven number.
TIP
• The oven numbers set to Not provided on the Temperature Control Set cannot be selected.
• The initial screen displays the smallest oven number among those assigned to isothermal
ovens on the Temperature Control Set.
Display Item
Name
Set Lower Limit Upper Limit
Unit
Remarks
Oven #
Oven number
1
3
Oven air
press
○
Alpanumeric: 18 characters
TPM vortex
press
○
Alpanumeric: 18 characters
FPD vortex
press
○
Alpanumeric: 18 characters
