<7. Troubleshooting>
7-7
IM 11B08A01-01E
 Level 2
 D/I Alarm
No. MESSAGE Alarm Contents Threshold Item Setting Value
201 DI#1 ALARM DI#1 Alarm
202 DI#2 ALARM DI#2 Alarm
203 DI#3 ALARM DI#3 Alarm
204 DI#4 ALARM DI#4 Alarm
205 DI#5 ALARM DI#5 Alarm
206 DI#6 ALARM DI#6 Alarm
207 DI#7 ALARM DI#7 Alarm
208 DI#8 ALARM DI#8 Alarm
209 DI#9 ALARM DI#9 Alarm
210 DI#10 ALARM DI#10 Alarm
211 DI#11 ALARM DI#11 Alarm
212 DI#12 ALARM DI#12 Alarm
213 DI#13 ALARM DI#13 Alarm
214 DI#14 ALARM DI#14 Alarm
215 DI#15 ALARM DI#15 Alarm
216 DI#16 ALARM DI#16 Alarm
217 DI#17 ALARM DI#17 Alarm
218 DI#18 ALARM DI#18 Alarm
219 DI#19 ALARM DI#19 Alarm
220 DI#20 ALARM DI#20 Alarm
221 DI#21 ALARM DI#21 Alarm
222 DI#22 ALARM DI#22 Alarm
223 DI#23 ALARM DI#23 Alarm
224 DI#24 ALARM DI#24 Alarm
225 DI#25 ALARM DI#25 Alarm
226 DI#26 ALARM DI#26 Alarm
227 DI#27 ALARM DI#27 Alarm
228 DI#28 ALARM DI#28 Alarm
229 DI#29 ALARM DI#29 Alarm
230 DI#30 ALARM DI#30 Alarm
231 DI#31 ALARM DI#31 Alarm
232 DI#32 ALARM DI#32 Alarm
 Fixed Alarm
No. MESSAGE Alarm Contents Threshold Item Threshold Threshold
Setting
251 OVERRIDE Override N/A
252 DUAL ETHER ERR Wrong def. of dual
Ethernet
IP address Invalid IP address
setting
Ethernet setting
screen
253 FILE_READ_ERR File reading error File Error to read N/A
254 FILE_WRITE_ERR File writing error File Error to write N/A
261 HMI SYS ERR HMI system error DO contact for HMI
Fail
N/A
262 HMI COMM ERR HMI communication
error
DO contact for HMI
communication error
N/A
271 OVEN1 COOL ERR Oven 1 cooling error Temperature control
for programmed
temperature oven
Temperature control
does not start when
analysis starts.
N/A
272 OVEN2 COOL ERR Oven 2 cooling error
273 OVEN3 COOL ERR Oven 3 cooling error
281 C-OVER
Calibration error Calibration range Exceeds the set
value.
Peak setting
screen
282 C-REPT Calibration
repeatability failure
Repeatable
calibration range
Exceeds the set
value.
Peak setting
screen
283 C-COEF Failure of calibration
coeffi cient
Invalid calibration
coeffi cient
Exceeds the set
value.
Peak setting
screen
291 CONC OUT Concentration
abnormal
Concentration Exceeds the set
value.
Alarm setting
screen
292 RT OUT Retention time
abnormal
Retention time Exceeds the set
value.
Alarm setting
screen
293 DEV OUT Variation coeffi cient
abnormal
Variation coeffi cient Exceeds the set
value.
Alarm setting
screen
294 TAIL OUT Tailing coeffi cient
abnormal
Tailing coeffi cient Exceeds the set
value.
Alarm setting
screen
2nd Edition : May 11, 2012-00
