<4. GC-HMI (touch panel)>
4-20
IM 11B08A01-01E
GCM information
Listed in order of GCM number
↓
F0421.ai
SYS information
Press this to display the overview screen.
Active GCM when the
background is blue
Not active GCM when the
background is other than blue
Figure 4.21 Example of Overview Screen
 Description of icons and buttons
The icons and buttons provided on the overview screen are as described below.
F0422.ai
(5)
(1) (2) (6) (7) (9) (8) (4) (3) (10) (11)
Figure 4.22 Overview Screen Display Elements
