<5. EtherLCD>
5-42
IM 11B08A01-01E
F1 (Menu): Displays the Table Menu screen.
F5 (Oven #): Selects an oven number.
F6 (Gas #):
Selects a utility gas number.
TIP
• If the detector number is set to --- (not used), the Utility gas function and the Utility gas type are shown as ---.
• The oven numbers set to Not provided on the Temperature Control Set cannot be selected.
• The detector numbers set to Not provided on the Detector Set screen cannot be selected.
• The initial screen displays the smallest oven number among those assigned to isothermal
ovens on the Temperature Control Set.
Display Item Name Set Lower Limit Upper Limit Unit Remarks
Oven # Oven number 1 3
Utility gas # Utility gas number 1 4
Detector
number
○ ---
1-1
1-2
2-1
2-2
3-1
3-2
* --- indicates not used.
Utility gas
function
Utility gas function ○ ---
Burner fuel
Burner air
Make up
* The initial value is ---.
Utility gas
type
Utility gas type ○ * --- (not used)
H
2
He
Ar
N
2
Air
* The initial value is ---.
* The value becomes effective
by turning power Off and
then On.
Utility gas
pressure
Utility gas pressure ○ 0
0.0
490
71.0
kPa
psi
Numeric entry
Limits vary depending on the
unit (see left).
psi (see the defi nition of SI
units.)
Utility gas
fl ow rate
Utility gas fl ow rate ○ Alphanumeric: 10 characters
e.g., 100 ml/s, 0.5 ul/s, etc.
*: The settings are valid after rebooting or turning off/on its power.
1 1 / 1 1 / 2 2
1 5 : 1 5 : 4 5 Operating Parameters (3/8)
Oven # 1 Det # 1
Carrier gas number - - -
>
- Vent-D ( FID ) fl owrate
- VENT-REF fl owrate
Menu Oven# Det#
F1 F2 F3 F4 F5 F6
Figure 5.55 Example of the operating parameters screen (3/8)
2nd Edition : May 11, 2012-00
