<5. EtherLCD>

5-82

IM 11B08A01-01E

1 1 / 1 1 / 2 2
1 5 : 1 5 : 4 5

D/O Setup

Slot # 1 DO # 1
>

- Process assign Stream

- Stream 1 (GCM 1)

Status

Slot#

DO#

Figure 5.91

Example of D/O setup screen (setting the Process assign to stream)

• The GCM number displayed on the screen cannot be set.
• When an Over limit value is set as the stream, “Over limit” is displayed in the bottom line and

the set value is not shown.

1 1 / 1 1 / 2 2
1 5 : 1 5 : 4 5

D/O Setup

Slot # 1 DO # 1
>

- Process assign Operation mode

- GCM number 1
- Operation mode Stop

Status

Slot#

DO#

Figure 5.92

Example of D/O setup screen (setting the Process assign to 0peration mode)

• When an Over limit value is set as a GCM number, “Over limit” is displayed in the bottom

line and the set value is not shown.

• Warming up time for the currently operated stream is not included in case of Run.

1 1 / 1 1 / 2 2
1 5 : 1 5 : 4 5

D/O Setup

Slot # 1 DO # 1
>

- Process assign Alarm

- GCM number 1
- Alarm level 1 AAAAAAA
- Alarm level 2 AAAAAAA
- Composition Alarm

AAAAAAA

Status

Slot#

DO#

Figure 5.93

Example of D/O setup screen (setting the Process assign to Alarm)
