<5. EtherLCD>
5-95
IM 11B08A01-01E
Point a cursor to selection and press the Set/Ent key, and options are displayed in the second
line below.
Select either Yes or NA.
Display Item Name Set Lower Limit Upper Limit Unit Remarks
SYS # 1 6
Oven # 1 3
Valve Valve set ○ * NA (default), Yes
Some inputs disabled
detector Detector type
Display
Detector Setup
○ * NA (default), Yes
Some inputs disabled
Carrier EPC Setup ○ * NA (default), Yes
Some input disabled
*: The settings are valid after rebooting or turning off/on its power.
5.4.24 User Programming
1 1 / 1 1 / 2 2
1 5 : 1 5 : 4 5 User Programming
Period # 1
>
- GCM number 1
- Auto start Off
- Exec interval Day
- Interval (Day) 1
- Interval (Hour) * * *
- Interval (Min)
* * * *
- Interval (Sec) * * * *
- Exec SYS number *
Menu Calend Delete Period#
F1 F2 F3 F4 F5 F6
Figure 5.107 Example of User Programming screen (Period script)
F1 (Menu): Displays the Table menu screen.
F2 (Calend): Displays the User Programming screen (End of peak detection script).
F3 (Delete):
Displays the period script delete screen.
F6 (Period #): Specifi es a Period script number.
• If a peak is not assigned to the stream set for the specifi ed GCM number, an error occurs
when period script is executed.
• When a GCM number is 0, all set values including the GCM number are displayed as *
(asterisk).
2nd Edition : May 11, 2012-00
5
