<5. EtherLCD>
5-54
IM 11B08A01-01E
Usage set, tracking exec and tracking coef updating share one setup in the SYS. In other words,
changing the method number after a set change is made by one SYS method displays the
changed setup.
Display Item Name Set Lower Limit Upper Limit Unit Remarks
GCM # GCM number 1 6
SYS # SYS number 1 6
Method # Method number 1 6
Usage set ○ Not used
Used
When SYS is not used, stop
status (no action) will occur
during run.
Analysis
cycle
○ 10.0 Main cycle seconds Some data are invalid.
End of peak
detect
○ 5.0 Analysis
cycle
seconds Some data are invalid.
Tracking exec ○ Not executed/executed
Tracking coef
updating
○ No updating/updating
 SYS Method Copy Screen
Press F5 (Copy).
1 1 / 1 1 / 2 2
1 5 : 1 5 : 4 5 SYS method copy
Source GCM #1 / SYS #1 / Method #1
> - Destination SYS number 0
- Destination Method number 0
Menu Main Exec
F1 F2 F3 F4 F5 F6
Figure 5.68 Example of the SYS method copy screen
F1(Menu): Displays Table Menu screen.
F2(Main): Displays SYS Method Setup screen (Main).
F5(Exec): Executes the method copy.
(4) Selecting the copy target method number displays Copy target method number: in the
second line on the bottom. Then enters the copy target method number.
(5) Pressing F5 (Exec) executes the method copy under the normal operation and displays
COPY END in the second line on the bottom. SYS number and method number of the copy
target are displayed as 0.
• The set range for Copy target SYS number is the SYS number belonging to the assigned
GCM.
• Usage set, tracking exec and tracking coef updating share one setup in the SYS. In other
words, the SYS method copy is not applicable.
• Before copying the SYS method, confi rm the analysis cycle and the main cycle.
When the analysis cycle of copy source is greater than (>) the main cycle of copy target, a
copy failed message is output.
