5.3 Operation Display screen
Pressing the Operation menu key navigates to the Operation Display screen.
1 1 / 1 1 / 2 2
1 5 : 1 5 : 4 5 Operation Menu (1/2) 1 1 / 1 1 / 2 2
1 5 : 1 5 : 4 5 Operation Menu (2/2)
> - A/O Chromatogram Operation
> - Status Switching
- A/O Operation - Password Setup
- D/O Operation
- Remote A/O Operation
- Remote D/O Operation
- User Program Operation
- SD card Operation
- Auto Tuning Operation
- Det Adjustment
F1 F2 F3 F4 F5 F6 F1 F2 F3 F4 F5 F6
Figure 5.25 Operation menu screen
To show the Menu screen below, press the Next key.
TIP
A/O Operation, D/O Operation, Remote A/O Operation, Remote D/O Operation, SD Card Operation and Auto
Tuning Operation are selectable only when all the GCMs are in Manual status and in Stop mode.
• The Det Adjustment screen for the detector with the smallest number is displayed.
• If the Analog output num is 0 on the GCCU screen, the Remote A/O Operation status cannot
be selected.
• During auto tuning, the screen navigates automatically to the Auto Tuning Operation screen.
5.3.1 A/O Chromatogram Operation
1 1 / 1 1 / 2 2
1 5 : 1 5 : 4 5 A/O Chromatogram Operation
Oven #1 Det #1 ( TCD )
Auto gain None
Whole gain value 0
Auto zero Off
Auto zero value 0.0000 mV
Auto zero time 0.0 s
Menu A.Zero C.Zero Table Oven# Det#
F1 F2 F3 F4 F5 F6
Figure 5.26 Example of the A/O chromatogram operation screen
F1 (Menu): Displays the Operation Menu screen.
F2 (A.Zero): Executes the Manual zero.
F3 (C.Zero): Clears values to zero.
F4 (Table):
Displays the Det Status Setup screen.
F5 (Oven #): Sets an oven number.
