<5. EtherLCD>
5-89
IM 11B08A01-01E
 Dual_ip setup screen
Execute the dual_ip setup.
Press F4 (Dual_ip).
1 1 / 1 1 / 2 2
1 5 : 1 5 : 4 5 Network Setup
Dual IP
>
- IP for dual 1 0. 0. 0. 0
> - IP for dual 2 0. 0. 0. 0
> - IP for dual 3 0. 0. 0. 0
> - IP for dual 4 0. 0. 0. 0
> - IP for dual 5 0. 0. 0. 0
> - IP for dual 6 0. 0. 0. 0
> - IP for dual 7 0. 0. 0. 0
> - IP for dual 8 0. 0. 0. 0
Menu Main Redundant
F1 F2 F3 F4 F5 F6
Figure 5.102 Example of network setup (Redundant) screen
F1 (Menu): Displays the Table menu screen.
F3 (Main): Displays the Main screen.
F4 (Redundant): Displays the Redundant setup screen.
* The redundant application will launch only when the Ethernet (ch2) is installed.
Display Item Name Set Lower Limit Upper Limit Unit Remarks
PHY-A IP
address
○
Gateway
IP_A
○
Subnet mask ○
PCAS confi g ○ 0: NA, 1: single, 2: dual
* 2: dual can be selected only
when Ethernet (ch2) is installed.
ASGW confi g ○ 0: NA, 1: single, 2: dual
* 2: dual can be selected only
when Ethernet (ch2) is installed.
DCS confi g ○ 0: NA, 1: single, 2: twin
* 2: twin can be selected only
when Ethernet (ch2) is installed.
Scaling coef ○ 0: Real, 1: 9999, 2: 65535
Virtual IP
address
○
PHY-B IP
address
○
Gateway
IP_B
○
Diag Interval ○ 500 3000 ms
2nd Edition : May 11, 2012-00
