<5. EtherLCD>
5-77
IM 11B08A01-01E
Display Item Name Set Lower Limit Upper Limit Unit Remarks
GCM #
Val #
Val number 1 6
Validation
stream
○ 0 31* * Only val streams belonging to
GCM can be set. (Stream setup
screen )
Validation
times
○ 0 30
Auto
validation
specifi cation
○ Not done, Done
5.4.11 Multirange Setup
When using peak setup-specifi c to set a range number, the multirange setup is made effective.
When synchronizing the data in the range number with peak setup-specifi c, changes can be
made bidirectionally.
1 1 / 1 1 / 2 2
1 5 : 1 5 : 4 5 Multirange Setup
Range # 1
>
- Process (Type) Distillation
- Process (Detail) Std B.P proc
Menu Get Range#
F1 F2 F3 F4 F5 F6
Figure 5.85 Example of multirange setup screen
F1 (Menu): Displays the Table Menu screen.
F4(Get): Gets the set values of the Process assign, measurement unit, measurement
range, etc. of the specifi ed peak.
F6 (Range #): Specifi es a range number (1 to 31).
Stream type
Range synchronization
Measurement Calibration Validation
Calibration
run
Sample run
— Valid Invalid Valid Invalid Invalid
Display Item Name Set Lower Limit Upper Limit Unit Remarks
Range # Range number 1 31
Process
(Type)
○ See the Display Data List for
Peak setup-specifi c screen.
Process
(Detail)
○ See the Display Data List for
Peak setup-specifi c screen.
Measurement
Unit
○ See the Display Data List for
Peak setup-specifi c screen.
Measuring
range
○ See the Display Data List for
Peak setup-specifi c screen.
Ref peak
number
○
0, 100%
value
○
2nd Edition : May 11, 2012-00
