<5. EtherLCD>
5-9
IM 11B08A01-01E
F6 (Slot #):
Sets a slot number.
TIP
• The Status is refreshed automatically at a fi xed interval (1 second).
• On the initial screen, the smallest slot number among those of the D/O cards inserted is displayed.
• For the slot number setting, only slot numbers of D/O cards can be accepted.
• Up to CH3 are displayed for DI/O cards.
• One GCM stream identifying signal can be applied to multiple D/O cards.
• In the case where the Stream identifi cation has been set on the GCM Setup screen, the D/O is used for that
purpose.
Example: Stream
identifi cation setup for the GCM1 (where the fi rst number of the stream
identifi cation D/O is 1)
Slot
1
2
Stream
identifi cation
DO1
DO2
DO3
DO4
DO5
DO1
Up to 3 streams Stream
identifying fl ag
Stream
identifi cation
Stream
identifi cation
Normal output Normal output Normal output
Up to 7 streams Stream
identifying fl ag
Stream
identifi cation
Stream
identifi cation
Stream
identifi cation
Normal output Normal output
Up to 15 streams Stream
identifying fl ag
Stream
identifi cation
Stream
identifi cation
Stream
identifi cation
Stream
identifi cation
Normal output
Up to 31 streams Stream
identifying fl ag
Stream
identifi cation
Stream
identifi cation
Stream
identifi cation
Stream
identifi cation
Stream
identifi cation
Display Item
Name
Set Lower Limit Upper Limit
Unit
Remarks
Slot #
Slot number
1
5
Absolute slot number
DO #
D/O contact number
1
5
Number Relative contact number
Output item
No assignment
Stream sequence
Stream
Operation mode
Alarm
Timing
Cal/Val
Str valve select
* See Note.
Status
Off, On
Note:
1: The selected GCM number and stream sequence number are displayed.
2: The selected stream number is displayed
3: The selected GCM number and operation mode are displayed.
4: The selected GCM number and alarm level/concentration alarm are displayed.
5: The selected SYS number, SYS method and sequence order selection are displayed.
6: The selected GCM number and calibration/validation number are displayed.
