<5. EtherLCD>
5-62
IM 11B08A01-01E
5.4.7 Stream Sequence
1 1 / 1 1 / 2 2
1 5 : 1 5 : 4 5 Stream Sequence (1/4) 1 1 / 1 1 / 2 2
1 5 : 1 5 : 4 5 Stream Sequence (2/4)
GCM # 1 Seq # 1 GCM # 1 Seq # 1
> - #01 Stream 1 ( s1 ) - Executed - #10 Stream ** (* * * * * * * *) - Unexecuted
- #02 Stream ** (* * * * * * * *) - Unexecuted - #11 Stream ** (* * * * * * * *) - Unexecuted
- #03 Stream ** (* * * * * * * *) - Unexecuted - #12 Stream ** (* * * * * * * *) - Unexecuted
- #04 Stream ** (* * * * * * * *) - Unexecuted - #13 Stream ** (* * * * * * * *) - Unexecuted
- #05 Stream ** (* * * * * * * *) - Unexecuted - #14 Stream ** (* * * * * * * *) - Unexecuted
- #06 Stream ** (* * * * * * * *) - Unexecuted - #15 Stream ** (* * * * * * * *) - Unexecuted
- #07 Stream ** (* * * * * * * *) - Unexecuted - #16 Stream ** (* * * * * * * *) - Unexecuted
- #08 Stream ** (* * * * * * * *) - Unexecuted - #17 Stream ** (* * * * * * * *) - Unexecuted
- #09 Stream ** (* * * * * * * *) - Unexecuted - #18 Stream ** (* * * * * * * *) - Unexecuted
Menu GCM# Seq# Menu GCM# Seq#
F1 F2 F3 F4 F5 F6 F1 F2 F3 F4 F5 F6
Figure 5.76 Example of the stream sequence set (1/4) screen
F1(Menu): Displays Table Menu screen.
F5(GCM#): Specifi es GCM number.
F6(Seq#): Specifi es a stream sequence number (1 to 8).
Same for pages 2, 3, and 4 (up to 31 streams can be set).
Streams other than that of the relevant GCM cannot be set.
Display Item Name Set Lower Limit Upper Limit Unit Remarks
Number of pages 1 4 Scheduling for up to 31 streams
GCM # 1 6
Seq # Stream sequence
number
1 8
nn (AAAA) Stream number
(Stream name)
○ 1 31 When the interval is Not
executed, an asterisk is
displayed.
* Only stream belonging to the
GCM can be set.
Stream name cannot be set.
Displays in 8 alphanumeric
characters.
Interval ○ Not executed, Executed
2nd Edition : May 11, 2012-00
