<6. Maintenance>
6-3
IM 11B08A01-01E
Table 6.3 Recommended Parts List for Periodical Replacement
Item Name Part Number Replacement
Interval
Note
Rotary Valve Valve Seat K9409ZA 100,000 cycles CSW (Rulon) (2xK9034DN)
K9034FF 0.33 μL (Rulon)
K9409ZE 1 μL (Rulon) (2xK9034DS)
K9409ZD 2 μL (Rulon) (2xK9034DR)
K9409ZC 3 μL (Rulon) (2xK9034DQ)
K9409ZB Over 10 μL (Rulon) (2xK9034DP)
K9034FR CSW (Tefl on)
K9402XX 0.33 μL (Tefl on)
K9034FL 1 μL (Tefl on)
K9034FK 2 μL (Tefl on)
K9034FJ 3 μL (Tefl on)
K9034FH Over 10 μL (Tefl on)
Valve Gland K9034BA 5-years CSW (SUS316)
K9034BP 0.33 to 3 μL (SUS316)
K9034BJ 10 μL (SUS316)
K9034BH 25 μL (SUS316)
K9034BG 50 μL (SUS316)
K9034BB 360 μL or more (SUS316)
K9034GX CSW (Hastelloy C)
K9034GV 0.33 to 3 μL (Hastelloy C)
K9034GS 25 μL (Hastelloy C)
K9034GR 50 μL (Hastelloy C)
K9034GN 360 μL or more (Hastelloy C)
Liquid Sampling
Valve
Seal Element K9402VG 50,000 cycles Rulon
K9402VH Tefl on
O-ring K9402UN 2-years
Filter Element L9862AG 1-year
Gasket L9862AC 1-year
L9862AD
Stream Switching
Valve
Diaphragm K9192WL 3-years Viton + Tefl on
K9192WV Silicone + Tefl on
Oven Heater K9409GE 5-years Isothermal Oven, 100 V, 110 °C or below
K9409GN Isothermal Oven, 100 V, over 110 °C
K9409GF Isothermal Oven, 110 V, 110 °C or below
K9409GP Isothermal Oven, 110 V, over 110 °C
K9409GG Isothermal Oven, 115 V, 110 °C or below
K9409GB Isothermal Oven, 115 V, over 110 °C
K9409GH Isothermal Oven, 120 V, 110 °C or below
K9409GC Isothermal Oven, 120 V, over 110 °C
K9409GS Isothermal Oven, 200 V
K9409GT Isothermal Oven, 220 V
K9409GU Isothermal Oven, 230 V
K9409GV Isothermal Oven, 240 V
Turbine K9400FA 5-years
Packing K9803SX 5-years For large isothermal oven
K9803SW For standard isothermal oven
Vortex tube K9803HE 5-years For FPD
6.2 Procedure for Replacing Parts
 Precautions for Parts Replacement
(1) Always observe the instructions in this manual when replacing parts.
(2) When disconnecting pipes, do not allow any oil or moisture to get inside the pipes.
