<5. EtherLCD>
5-34
IM 11B08A01-01E
 Detector type: TCD - Execution screen
Press F2 (Adjust).
1 1 / 1 1 / 2 2
1 5 : 1 5 : 4 5 Det Adjustment
Oven # 1 Det # 1 ( TCD )
> - Det operation Off
Voltage value 0.0 V
Cuttent value 0.0 mA
- Target current
Main << < > >>
F1 F2 F3 F4 F5 F6
Figure 5.45 Example of the detector type: TCD - execution screen
F2 (Main): Displays the Det Adjustment (Reset) screen.
F3 (<<): Decreases the value by 16 steps within the range of 0 to 255 (for the TCD, by
approximately 0.94 V within the range of 5.0 V to 20.0 V).
F4 (<): Decreases the value by 1 step within the range of 0 to 255 (for the TCD, by
approximately 0.06 V within the range of 5.0 V to 20.0 V).
F5 (>): Increases the value by 1 step within the range of 0 to 255 (for the TCD, by
approximately 0.06 V within the range of 5.0 V to 20.0 V).
F6 (>>): Increases the value by 16 steps within the range of 0 to 255 (for the TCD, by
approximately 0.94 V within the range of 5.0 V to 20.0 V).
• To toggle the Det On/Off status, set the cursor on the Det operation and press the Set/Ent
key. The screen displays “Setting succeeded” or “Setting failed” in the second line on the
bottom.
• If the Up/Down command keys are pressed to adjust the value within the range of 0 to 255
and the command is successfully sent internally, “Setting succeeded” is displayed. Users
can confi rm the results with the voltage value and current value refreshed every second.
• Selecting the Target current displays Target current (AAA/BB):. If the value 250/10 is
entered, it will be shown as 250+/–10 mA, 250 as 250+/– mA and 50/5 as +/–5 mA.
• The numbers of ovens to which no detectors are installed cannot be set via F5.
TIP
The Det operation, Voltage value and Current value are refreshed at a one-second interval.
2nd Edition : May 11, 2012-00
