1 alarm status screen – Yokogawa GC8000 Process Gas Chromatograph User Manual
Page 248
<4. GC-HMI (touch panel)>
4-61
IM 11B08A01-01E
F0481.ai
Press this icon.
Figure 4.81
Example of Alarm Screen
The alarm screen consists of the following screens:
Alarm status screen
Alarm history screen
Alarm details screen
4.7.1
Alarm Status Screen
Screen components are as shown below.
F0482.ai
GCM tab
Table scroll button
Alarm details
Alarm status
Figure 4.82
2nd Edition : May 11, 2012-00
4
