App.H-5
IM 11B08A01-01E
3. Description of Each Window
Script Edit window
Output window
GCM Setting/
Status window
Close
Menu
Toolbar
Standard toolbar
Status bar
Watch window
Execution toolbar
Figure 5 Confi guration of GCUD window
In the GCUD window, you can read/write, edit, import/export, print, and/or debug a script fi le in
conjunction with each window (Script Edit, Output, Watch, GCM Setting/Status). The Script Edit
window is used as the main window for controlling various windows and functions.
2nd Edition : May 11, 2012-00
App.H
