App.D-2

IM 11B08A01-01E

Holds the stream identifi cation signal of the latest measured stream other than calibration or

validation.

Actions of analog output and contact output are described in (2) through (4) below. For actions of

contact output other than stream identifi cation signals, see the Contact Output.



When Actual Stream is Set for Output Stream Number (without Stream

Identifi cation Signal)

Select Normal output for the AO chromatogram on the A/O setting screen to open the analog

hold output (analysis result output) setting screen (Figure 1). Specify the GCM number, output

stream number, peak number, and the upper and lower limits of the partial range for the peak of

which analysis results are to be output.
When an actual stream number is set for the output stream number, up to 2 analysis values of

different streams are output.

Set the stream identifi cation signal output to “None” for each GCM (Figure 2).

1 1 / 1 1 / 2 2
1 5 : 1 5 : 4 5

A/O Setup

(1/2)

1 1 / 1 1 / 2 2
1 5 : 1 5 : 4 5

A/O Setup

(2/2)

Slot #

1 AO # 1

Slot #

1 AO # 1

- GCM number 1

- #2 Output stream 2 (STR2)

- AO Chromatogram

Normal output

#2 Output peak 1 (H2)

- #1 Output stream 1 (STR1)

- #2 Percent span offset 0.900

#1 Output peak 1 (H2)

- #2 Percent zero offset

0.600

- #1 Percent span offset 1.000
- #1 Percent zero offset

0.000

Status

Slot#

AO#

Status

Slot#

AO#

Figure 1 Analog Hold Output: Example of Actual Streams to be set for output stream number (A/O

Setting Screen on GC-HMI EtherLCD)

1 1 / 1 1 / 2 2
1 5 : 1 5 : 4 5

GCM Setup

(2/2)

GCM # 1
>

- ATM valve number 1-1

Strm identifying None
- 1st num StrIdentify DO

Slot #5 -#1

- 1st num StrValve 1
- Stream valve num 4
- Distillation

None

GCM#

Figure 2 Stream Identifi cation Signal Output: None (GCM Setting Screen on GC-HMI EtherLCD)

Table 2 shows an example of analog output settings.
Figure 3 illustrates respective actions.
