<4. GC-HMI (touch panel)>
4-21
IM 11B08A01-01E
Table 4.5 Description of Overview Screen Display Elements
Symbol Item Description
(1)
Active GCM change button Indicates the GCM number.
Also used to set the GCM as an active GCM.
(2)
GCM alarm indicator Indicates the alarm status of the GCM.
No alarm
Level-1 alarm generated (blinking)
Level-2 alarm generated (blinking)
(3)
GCM operating status indicator Indicates the operating status of the GCM.
Manual
Process
(4)
GCM operating mode indicator Indicates the operating mode of the GCM.
Run
Pause
Stop
(5)
Operating status change button for all
GCMs
Changes the operating status of GCMs.
All GCMs
Each GCM (6) GCM operating status change button
(7)
Indicators of GCM measurement status,
stream number, and method number.
Indicates the stream sequence, stream number, and
method number of the GCM.
(8) SYS number indicator Indicates the SYS number (1 to 6) assigned to the GCM.
(9)
SYS operating status indicator Indicates the operating mode of the SYS.
Run
Pause
Stop
(10) Elapsed time bar graph Indicates the elapsed time on a bar graph.
(11)
Elapsed time/SYS analysis Indicates the elapsed time per interval as a numerical
value.
 Changing the Active GCM
Example: To make GCM2 active, follow this procedure:
(1) Press the GCM change button of GCM2, which is not currently active.
(2) When a confi rmation screen appears, press Yes.
2nd Edition : May 11, 2012-00
