App.d-22, 1) analysis value data (fi xed to 45 characters) – Yokogawa GC8000 Process Gas Chromatograph User Manual
Page 467
App.D-22
IM 11B08A01-01E
(1) Analysis value data (fi xed to 45 characters)
The data is output only when Execution is set to “Executed” and Output fl ag is set to “Provided”
on the Peak Setup-Specifi c screen.
The packets for the processes are classifi ed as follows:
Process
Type of packet
Distillation
Type B
Peak
Type A
Calculation
Linear 1 to 5
Ratio
Separation cape
Type C
Divisor
Type B
Base level
Signal level
Noise level
Deviation calc
No output
Heating value
Type B
AI
Type B
Program output
No output
● Type
A
If a unit other than ppm or % or no unit is used, data is not output.
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45
D
S
1
2
,
,
P
%
P M , A : C H L , A : C L L , T
.
A : R T
CR LF
└──┘
└──┘
└──────────┘ └─────┘
└───────────────────────────┘
└─────────────┘
└───────┘
└─────┘
a
b
c
d
e
f
g
h
a:
Stream number (01 to 31)
b:
Peak number (01 to 99) *Relative peak number
To address all 255 peak numbers, S comes in the second digit (from the head) for the peak numbers 01 to 99, 1 for the numbers
100 to 199, and 2 for the numbers 200 to 255.
c:
Analysis value (5 digits)
The data format for analysis values depends on the measurement range for the peak setting (see Table 11).
Analysis values are rounded.
Table 11
Data format for analysis values
Output value Measurement range
Remarks
n.nnn
0.001 to 9.999
9.999 is used for all values of 9.9995 or more.
nn.nn
10.000 to 99.999
99.99 is used for all values of 99.995 or more.
nnn.n
100.000 to 999.999
999.9 is used for all values of 999.95 or more.
nnnnn
1000.000 to 9999.999 99999 is used for all values of 99999.5 or more.
n: any value from 0 to 9.
d:
Unit (PPM, %)
e:
Concentration error alarm (A:CHL = Higher limit, A:CLL = Lower limit)
They will be dummy spaces if no error occurs.
f:
Retention time (0000.0 to 9999.9)
The unit is in seconds. The position of the decimal point is fi xed. 0000.0 is used for values of 0 or less and 9999.9 for those of
9999.9 or more.
g:
Retention time error alarm (A:RT)
They will be dummy spaces if no error occurs.
h:
Analyzer number (1 to 240) (zero suppression provided)
in the second digit from the head because the peak numbers are 01 to 99.
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45
D S
,
,
P
%
P M , A : C H L , A : C L L , T
.
A : R T
CR LF
└──┘
└──┘
└──────────┘ └─────┘
└───────────────────────────┘
└─────────────┘
└───────┘
a
b
c
d
e
f
g
b:
Peak number (01 to 99) *Relative peak number
2nd Edition : May 11, 2012-00
