<5. EtherLCD>
5-59
IM 11B08A01-01E
Enter a time with a tenkey.
Pressing F1 (Seq) navigates to the SYS sequential display screen.
Only valves belonging to the relevant SYS can be set by F6 (Valve#).
Display Item Name Set Lower Limit Upper Limit Unit Remarks
GCM # GCM number 1 6
SYS # SYS number 1 6
Method # Method number 1 6
Valve
Number
Valve number 1 − 1 3 − 7 0: None
1 to 3 Oven
1 to 7 Valve
1st to 3rd ON
Time
○ 0 Analysis
cycle − 2
seconds Valve time set
Some entry data are invalid.
* When ON time is invalid, OFF
time cannot be set.
1st to 3rd
OFF Time
○ ON time Cycle Time
− 2
seconds
 ATM Action Setting Screen
Press F4 (AtmV).
1 1 / 1 1 / 2 2
1 5 : 1 5 : 4 5 ATM Action Setting
GCM #1 / SYS #1 / Method #1
ATM valve 1-1
>
- 1st ON time * * * * * * * s
- 1st OFF time * * * * * * * s
- 2nd ON time * * * * * * * s
- 2nd OFF time * * * * * * * s
- 3rd ON time * * * * * * * s
- 3rd OFF time * * * * * * * s
Seq Gate Valve DO
F1 F2 F3 F4 F5 F6
Figure 5.73 Example of the ATM action setting screen
F1(Seq): Displays SYS sequential Display screen.
F2(Gate): Displays Gate of the action set screen.
F3(Valve): Displays ON/OFF time screen of a valve (1st, 2nd & 3rd of maximum No. 1 to
18).
F5(DO): Displays D/O Setup screen in the action set screen
• ATM valve number set in GCM setup is displayed for ATM valve number (display only).
Functions of the function keys F2, F3 and F5 are the same as those in SYS method setup (Part
1; Main).
