App.C-7
IM 11B08A01-01E
Power supply: 100 to 240 V AC ±10%,
50/60Hz ±5%, 10W or less
Earth: Protective earth
5.2 Signal interrupter
• For Ethernet twisted pair cables:
(Rack-mounted type: K9806AA, Desktop
type: K9806AB)
Number of port: 2
Communication speed: maximum of
100Mbps
Power supply: 24 V DC (Supplied from
External I/O Cutoff Output of CPU
board in GC8000)
Earth: Functional earth
• For RS-422 output: K9806AE
Number of port: 2
Communication speed: maximum of
38400bps
Power supply: 24 V DC (Supplied from
External I/O Cutoff Output of Serial
communication card in GC8000)
Earth: Functional earth
• For analog input: K9806AE
Number of input: 4
Input current: 4 to 20 mA DC
Input voltage: 1 to 5 V DC
Power supply: 24 V DC (Supplied from
External I/O Cutoff Output of Analog
input card in GC8000)
Earth: Functional earth
• For contact output (AC): K9806AN
Number of output: 5
Rated input: 240 V AC, 2A DC
Power supply: 24 V DC (Supplied from
External I/O Cutoff Output of Contact
output card in GC8000)
Earth: Protective earth
• For contact output (DC): K9806AJ
Number of output: 5
Rated input: 30 V DC, 2A DC
Power supply: 24 V DC (Supplied from
External I/O Cutoff Output of Contact
output card in GC8000)
Earth: Functional earth
