<5. EtherLCD>
5-18
IM 11B08A01-01E
5.2.10 Standard B.P data
1 1 / 1 1 / 2 2
1 5 : 1 5 : 4 5 Standard B.P data (1/7) 1 1 / 1 1 / 2 2
1 5 : 1 5 : 4 5 Standard B.P data (2/7)
GCM # 1 GCM # 1
% Elapsed time B.P % Elapsed time B.P % Elapsed time B.P % Elapsed time B.P
0.5 0.0 0.0 8 0.0 0.0 16 0.0 0.0 24 0.0 0.0
1 0.0 0.0 9 0.0 0.0 17 0.0 0.0 25 0.0 0.0
2 0.0 0.0 10 0.0 0.0 18 0.0 0.0 26 0.0 0.0
3 0.0 0.0 11 0.0 0.0 19 0.0 0.0 27 0.0 0.0
4 0.0 0.0 12 0.0 0.0 20 0.0 0.0 28 0.0 0.0
5 0.0 0.0 13 0.0 0.0 21 0.0 0.0 29 0.0 0.0
6 0.0 0.0 14 0.0 0.0 22 0.0 0.0 30 0.0 0.0
7 0.0 0.0 15 0.0 0.0 23 0.0 0.0 31 0.0 0.0
Menu GCM# Menu GCM#
F1 F2 F3 F4 F5 F6 F1 F2 F3 F4 F5 F6
Figure 5.20 Example of the standard B.P data screen
F1 (Menu): Displays the Status Menu screen.
F6 (GCM #): Specifi es a GCM number.
• Display data are not refreshed automatically.
Display Item Name Set Lower Limit Upper Limit Unit Remarks
GCM # GCM number 1 6
% Distill % 0.5 99.5 % 0.5, 1 to 99 and 99.5
Elapsed time 0.0 21600.0 Seconds
B.P –999.9 9999.9 The unit depends on the
Temperature unit
set on the
SimDis Setup screen.
Reference:
The actual possible value range
is from –259.0

C to 1013.0

C or
–434.2

F to 1855.4

F.
*

F = 1.8  
C + 32
5.2.11 Operation Status
To show the Status Menu (1/2), press .
F1 (Menu): Displays the Table Menu screen.
F2 (GC): Displays the Total Operation Time screen.
F3 (Oven): Displays the Valve Operation Count screen.
F4 (StrV): Displays the Stream Valve Operation Count screen.
F5 (Det): Displays the Detector Operation Count screen.
F6 (Oven #): Specifi es an oven number.
2nd Edition : May 11, 2012-00
