<5. EtherLCD>
5-47
IM 11B08A01-01E
5.4.3 Temperature Setup
1 1 / 1 1 / 2 2
1 5 : 1 5 : 4 5 Temperature Setup
Oven # 1
>
- Oven max temp 60.0 degC
- Oven temp setpoint 60.0 degC
- LSV temp setpoint 60.0 degC
- FPD temp setpoint 0.0 degC
Menu Oven#
F1 F2 F3 F4 F5 F6
Figure 5.61 Example of the temperature setup screen
F1 (Menu): Displays the Table Menu screen.
F6 (Oven #): Specifi es an oven number.
• If the LSV and FPD are not installed, the pertinent values are shown as * (asterisk).
• If the Temp type is set to Not provided on the Temperature Control Set, the temperature
setup is not available.
Display Item Name Set Lower Limit Upper Limit Unit Remarks
Oven # Oven number 1 3
Oven max
temp
○ 5 See
Remarks.
°C No explosion: 320°C
T1: 320°C
T2: 225°C
T3: 145°C
T4: 95°C
* The value varies depending on
the explosionproof specifi cation.
Oven temp
setpoint
○ 5 Oven max
temp
°C
LSV temp
setpoint
○ 60 See
Remarks.
°C No explosion: 250°C
T1: 250°C
T2: 225°C
T3: 145°C
T4: 95°C
FPD temp
setpoint
○ 0 60 °C
2nd Edition : May 11, 2012-00
