<5. EtherLCD>

5-91

IM 11B08A01-01E

Display Item

Name

Set Lower Limit Upper Limit

Unit

Remarks

R-AO#

1 (5)

GCM number
#1 Output

stream

○

0, 1

(99), 31

#2 Output

stream

○

0, 1

#1, #2 Output

peak

0, 1

999

#1, #2 Partial

○

0.001

1.000

#1, #2 Partial

low

○

0.000

0.999

5.4.22 GCM

Setup

1 1 / 1 1 / 2 2
1 5 : 1 5 : 4 5

GCM Setup

(1/2)

1 1 / 1 1 / 2 2
1 5 : 1 5 : 4 5

GCM Setup

(2/2)

GCM # 1

- SYS 1 Yes

- ATM valve number 1-1

- SYS 2 No

Strm identifying None

- SYS 3 No

- 1st num StrIdentify DO

Slot #5 -#1

- SYS 4 No

- 1st num StrValve 0
- Stream valve num 0
- Distillation

Provided

GCM#

Figure 5.105

Example of GCM setup screen

F1 (Menu):

Displays the Table menu screen.

F6 (GCM #): Specifi es a GCM number.

When F6 (GCM #) is pressed, GCM No. appears in the second line below.
When the numeric keypad is used to select the GCM number and Set/Ent is pressed, the GCM
setup of that number is selected.

The following ovens can be set by SYS.
Up to 2 SYSs can be set for one oven.
Up to 4 SYSs can be set for two ovens.
Up to 6 SYSs can be set for three ovens.
Once one of SYSs is set to Yes and you move to other GCM numbers, ***** is displayed, and
“Already set in other GCM” is displayed in the second line below and it cannot be set for any
other GCM even though the SYS is about to be selected again. When more than the maximum
amount of SYSs is about to be selected, “Cannot select any more” is displayed in the second line
below and any more SYS cannot be selected.
On the fundamental system set screen, when the stream valve kind is set to Binary Output (Air),
only GCM 1 can be set.
When the ATM valve number area is selected and the Set/Ent key is pressed, an ATM valve
number is displayed in the second line below (1-1 to 3-2).
Use the up and down key to select it and press the Set/Ent key, and the number is refl ected.
On the ATM valve setup screen, when an ATM valve that has not been set to installed is selected,
“Not installed” is displayed.

2nd Edition : May 11, 2012-00
