Chapter 3 Operating Principles | PCI-DMC-A01 / PCI-DMC-B01

Revised March, 2012

3-63

3.18 Change Velocity

3.18.1 Function

List

Table 3.18

Function Name

_DMC_01_start_sa_move_2seg
_DMC_01_start_ta_move_2seg
_DMC_01_start_sr_move_2seg
_DMC_01_start_tr_move_2seg

3.18.2 Sample

Application

Program Appearance

Figure 3.91

1) Card initialization

Click on the “Initial” button to open and initialize the card.
For a detailed description of card initialization, please refer to “Open card” and “Card
initialization” in Section 3.1.2.
