42.2 _misc_app_get_circle_center_point
FORMAT
I16 PASCAL _misc_app_get_circle_center_point (I32 Start_X, I32 Start_Y, I32 End_x,
I32 End_y, F64 Angle, I32* Center_X, I32* Center_Y)
Purpose
Retrieves center point coordinates (X, Y) required for arc interpolation.
Parameters
Name
Data Type
Unit
Description
Start_X I32
Number
of
pulses Starting
X-coordinate
Start_Y
I32
Number of pulses
Starting Y-coordinate
End_x I32
Number
of
pulses Endpoint's
X-coordinate.
End_y
I32
Number of pulses
Endpoint's Y-coordinate.
Angle
F64
Degree (°)
Set arc angle. One full arc is 360º
Center_X
I32*
Number of pulses
Center point's X-coordinate.
Center_Y I32*
Number
of
pulses
Center point's Y-coordinate.
Example
I32 Start_X=0, Start_Y=0;
I32 End_x=100000, End_y0;
I32 Center_X, Center_Y;
F64 Angle=180;
I16 status = _misc_app_get_circle_center_point (Start_X, Start_Y , End_x, End_y, Angle,
&Center_X, &Center_Y);
