Chapter 30 4-Channel Analog Input Remote I/O Module API | PCI-DMC-A01 / PCI-DMC-B01

30-4

Revised March, 2012

30.3 _DMC_01_set_04ad_zero_scale

FORMAT

I16 _DMC_01_set_04ad_zero_scale (U16 CardNo, U16 NodeID, U16 SlotID, U16 channelno)


Purpose

Sets AD zero level for range calibration.


Parameters

Name

Data Type

Unit

Description

CardNo U16

Number

Unit

CardNo is between 0~15

NodeID

U16

Number Unit

Node ID is between 0~63

SlotID U16

Number

Unit

0

ChannelNo

U16

Number Unit

Channel ID is between 0~3


Example

U16 CardNo = 0;
U16 NodeID = 1;
U16 SlotID = 0;
U16 channelno = 2;

I16 status = _DMC_01_set_04ad_zero_scale (CardNo, NodeID, SlotID, channelno);
