Delta Electronics High-Speed PCI 12-Axis Motion Control Card PCI-DMC-A01 User Manual
Page 424

Chapter 30 4-Channel Analog Input Remote I/O Module API | PCI-DMC-A01 / PCI-DMC-B01
30-6
Revised March, 2012
30.5 _DMC_01_set_04ad_full_scale
FORMAT
I16 _DMC_01_set_04ad_full_scale (U16 CardNo, U16 NodeID, U16 SlotID, U16 channelno)
Purpose
Sets AD maximum level for range calibration.
Parameters
Name
Data Type
Unit
Description
CardNo U16
Number
Unit
CardNo is between 0~15
NodeID
U16
Number Unit
Node ID is (0~12)
SlotID U16
Number
Unit
0
ChannelNo
U16
Number Unit
Channel ID is between 0~3
Example
U16 CardNo = 0;
U16 NodeID = 1;
U16 SlotID = 0;
U16 channelno = 0;
I16 status = _DMC_01_set_04ad_full_scale (CardNo, NodeID, SlotID, channelno);
