Chapter 39 Compare API | PCI-DMC-A01 / PCI-DMC-B01

39-18

Revised March, 2012

39.16 _DMC_01_set_compare_channel_polarity

FORMAT

I16 PASCAL _DMC_01_set_compare_channel_polarity (U16 CardNo, U16 inverse)


Purpose

Sets Compare level.


Parameters

Name

Data Type

Unit

Description

CardNo

U16

Number Unit CardNo is between 0~15

Inverse

U16

Number Unit

0: Normal
1: Inverse


Example

U16 CardNo = 0;
U16 Inverse = 1;

I16 status = _DMC_01_set_compare_channel_polarity (CardNo, inverse);
