Chapter 29 4-Channel Analog Output Remote I/O Module API | PCI-DMC-A01 / PCI-DMC-B01

29-2

Revised March, 2012

29.1 _DMC_01_rm_04da_set_output_value

FORMAT

I16 PASCAL _DMC_01_rm_04da_set_output_value (U16 CardNo, U16 NodeID, U16 SlotID,
U16 ChannelNo, U16 Value)


Purpose

Sets value of DA output.


Parameters

Name

Data Type

Unit

Description

CardNo U16

Number

Unit CardNo is between 0~15

NodeID

U16

Number Unit Node ID is between 0~12

SlotID U16*

Number

Unit

0

ChannelNo

U16

Number Unit Channel ID is between 0~3

Value

U16

Number Unit Output is between 0 ~ 65535


Example

U16 CardNo = 0;
U16 NodeID = 1;
U16 SlotID = 0;
U16 ChannelNo = 0;
U16 Value = 0x5ff;

I16 status = _DMC_01_rm_04da_set_output_value (CardNo, NodeID, SlotID, ChannelNo,

Value);
