Chapter 37 Security API | PCI-DMC-A01 / PCI-DMC-B01

Revised March, 2012

37-3

37.3 _DMC_01_write_security

FORMAT

I16 PASCAL _DMC_01_write_security (U16 CardNo, U16 page, U16 array )


Purpose

Writes security data to memory block specified by the Master Card.


Parameters

Name

Data Type

Unit

Description

CardNo U16

Number

Unit

CardNo is between 0~15

Page

U16

Number Unit

Specified memory page number for write

array U16

Number

Security

data

to write to specified memory


Example

U16 CardNo=0;
U16 page=0;
U16 array={1,4,7,11,0a,ff,12,8,0b,10,3,5,c1,14,0d,6};

I16 status =_DMC_01_wtite_security( CardNo, page, array );

37.4 _DMC_01_ write_security_status

FORMAT

I16 PASCAL _DMC_01_write_security_status (U16 CardNo, U16 status)


Purpose

Before the Master Card writes security data, writes function enable to memory.


Parameters

Name

Data Type

Unit

Description

CardNo U16

Number

Unit

CardNo is between 0~15

status

U16

Flag

Write function enable (0:disable,1:enable) to
memory


Example

U16 CardNo=0;
U16 status=1;

I16 status = _DMC_01_write_security_status (CardNo, status);
