Chapter 3 Operating Principles | PCI-DMC-A01 / PCI-DMC-B01

3-16

Revised March, 2012

3.6 Velocity Motion Control (1)

3.6.1 Function

List

Table 3.6

Function Name

_DMC_01_set_velocity_mode
_DMC_01_set_velocity
_DMC_01_set_velocity_stop
_DMC_01_get_rpm

3.6.2 Sample

Application

Program Appearance

Figure 3.25

1) Card initialization

Click on the “Initial” button to open and initialize the card.
For a detailed description of card initialization, please refer to “Open card” and “Card
initialization” in Section 3.1.2.

2) Set Servo Node ID and enable motion status display

Figure 3.26
