Chapter 42 Other API | PCI-DMC-A01 / PCI-DMC-B01

42-6

Revised March, 2012

42.6 _DMC_01_set_dda_data

FORMAT

I16 PASCAL _DMC_01_set_dda_data (U16 CardNo, U32* abs_pos)


Purpose

Enters DDA Table data.


Parameters

Name

Data Type

Unit

Description

CardNo U16

Number

Unit

CardNo is between 0~15

Abs_Pos

U32*

Numerical data This field is a an array for data from 12 axes


Example

U16 CardNo = 0;
U32 Abs_Pos[0][11] = {1000,2000,0,0,0,0,0,0,0,0,0,0};
//Abs_Pos is a 12-axis data array. Maximum Buffer is 1000 entries. One DDA Table entry is
executed each ms. Please note that other commands will not be accepted before the Buffer
finishes executing (e.g. Sd_Stop).
I16 status = _DMC_01_set_dda_data (CardNo, Abs_Pos);
//Other Node without DDA Table enabled can continue to execute other actions as normal.

42.7 _DMC_01_get_dda_cnt

FORMAT

I16 PASCAL _DMC_01_get_dda_cnt (U16 CardNo, U16* dda_cnt)


Purpose

Retrieves number of remaining entries in DDA Table.


Parameters

Name

Data Type

Unit

Description

CardNo U16

Number

Unit

CardNo is between 0~15

dda_cnt

U16*

Numerical data

Current number of remaining entries in DDA
Table


Example

U16 CardNo = 0;
U16 dda_cnt;

I16 status = _DMC_01_get_dda_cnt (CardNo, & dda_cnt);;
