background image

Chapter 2 Command Return Values and Messages | PCI-DMC-A01 / PCI-DMC-B01

Revised March, 2012

2-1

Chapter 2 Command Return Values

and Messages

2.1 Error

Codes

When you use API for PCI-DMC-A01, the function library will generally return one of the
error codes listed in Table 2.1.

If the API function's return value is 0, then the API function was executed successfully. If
the API function returns some other error code, then an error may have occurred during
operation or in the hardware connection. You can troubleshoot the problem by referring to
the error code description.

Table 2.1

Error Return

Code

(Decimal)

Error Code

Error Description

0

ERR_NoError

API executed successfully

3

ERR_CardNoError

Card number error. Please check the number set
by the DIP Switch on the card.

5

ERR_bootmodeErr

Unable to boot DSP procedure

6

ERR_downloadcode

DSP memory program read/write error

7

ERR_downloadinit

DSP memory data read/write error

8

ERR_PCI_boot_first

“_DMC_01_pci_initial” AP function must be
launched first

11

ERR_AxisNoError

Axis number error (too large)

12

ERR_IPO_First

Must be in IPO mode

13

ERR_Target_reach

Target must be in position for Mode 1 operation

14

ERR_Servo_on_first

Must be set to Servo on

15

ERR_MPG_Mode

Unable to clear position in Manual Pulse
Generator (MPG) mode

16

ERR_PDO_TG

Unable to return acknowledgement when sending
command to module in PDO mode

17

ERR_ConfigFileOpenError

Error opening configuration file

18

ERR_Ctrl_value

Command code error

19

ERR_Security_Fifo

Write error using Security Fpga

20

ERR_Security_Fifo_busy

Security Fpga is busy
