Chapter 28 4-Channel Pulse Interface (Mode 1) Motion Control API | PCI-DMC-A01 / PCI-DMC-B01

28-2

Revised March, 2012

Function Name

Description

_DMC_01_rm_04pi_md1_set_soft_limit

Enable/disable software limit under RM04PI
Mode 1

_DMC_01_rm_04pi_md1_get_soft_limit_status

Get current 4-axis software limit contact status
under RM04PI Mode 1

_DMC_01_rm_04pi_md1_set_sld

Enable SLD port (DI3) and set profile

_DMC_01_rm_04pi_md1_get_mc_error_code

When alarm code is 299, get motion control
error message under RM04PI Mode 1

_DMC_01_set_rm_04pi_ref_counter Select reference counter for re-connection

under RM04PI Mode 1
