Chapter 3 Operating Principles | PCI-DMC-A01 / PCI-DMC-B01

Revised March, 2012

3-111

3.29 Position Compare

3.29.1 Function

List

Table 3.29

Function Name

_DMC_01_set_compare_channel_position
_DMC_01_get_compare_channel_position
_DMC_01_set_compare_ipulse_mode
_DMC_01_set_compare_channel_direction
_DMC_01_set_compare_channel_trigger_time
_DMC_01_set_compare_channel_one_shot
_DMC_01_set_compare_channel_source
_DMC_01_channel0_position_cmp
_DMC_01_channel1_output_enable
_DMC_01_channel1_output_mode
_DMC_01_channel1_get_io_status
_DMC_01_channel1_get_gpio_out
_DMC_01_channel1_get_fifo_status
_DMC_01_channel1_get_fifo_counter
_DMC_01_channel1_position_compare_table
_DMC_01_channel1_position_compare_table_level
_DMC_01_channel1_position_compare_table_cnt
_DMC_01_set_compare_channel_polarity
