Chapter 3 Operating Principles | PCI-DMC-A01 / PCI-DMC-B01

3-10

Revised March, 2012

3.4.2 Function

List

Table 3.4

Function Name

_DMC_01_set_home_config
_DMC_01_set_home_move
_DMC_01_escape_home_move

3.4.3 Sample

Application

Program Appearance

Figure 3.17

1) Open card and initialization

Click on the “Initial” button to open and initialize the card.
For a detailed description of card initialization, please refer to “Open card” and “Card
initialization” in Section 3.1.2.
