background image

Chapter 8 Using SDO Protocol API | PCI-DMC-A01 / PCI-DMC-B01

Revised March, 2012

8-7

8.3 _DMC_01_get_canopen_ret

FORMAT

I16 PASCAL _DMC_01_get_canopen_ret (U16 CardNo, U16* COBID, U8* value)


Purpose

Retrieves data returned by CANOPEN (SDO related data).


Parameters

Name

Data Type

Unit

Description

CardNo U16

Number

Unit CardNo is between 0~15

COBID

U16*

Number

CAN object ID

value U8*

Number

Data contained within object
Value[0]: SDO Message response

If content is 32-bit long, value is 43
If content is 16-bit long, value is 4b
If content is 8-bit long, value is 4f
Write successful, value is 60
Error report, value is 80

Value[1]: Index(Low byte)
Value[2]: Index(High byte)
Value[3]: Sub index
Value[4]: Data low word (Low byte)
Value[5]: Data low word (High byte)
Value[6]: Data high word (Low byte)
Value[7]: Data high word (High byte)


Example

U16 CardNo=0;
U16 COBID=0;
U8 value[8]={0};
I16 status= _DMC_01_get_canopen_ret (CardNo, &COBID, value);
