Chapter 20 2-Axis Arc Interpolation Motion Control API | PCI-DMC-A01 / PCI-DMC-B01

Revised March, 2012

20-27

20.13 _DMC_01_start_spiral_xy

FORMAT

I16 PASCAL _DMC_01_start_spiral_xy (U16 CardNo, U16* NodeID, U16* SlotID,
I32 Center_X, I32 Center_Y, I32 spiral_interval, I32 spiral_angle, I32 StrVel, I32 MaxVel,
F64 Tacc, F64 Tdec,U16 m_curve,U16 m_r_a)


Purpose

Carries out 2-axis spiral motion (Known conditions: center coordinates for X and Y axes).


Parameters

Name

Data Type

Unit

Description

CardNo U16

Number

Unit

Node ID of card used for motion displacement
along X-axis and Y-axis

NodeID

U16*

Number Unit

Holds Node ID sets used for carrying out spiral
motion
NodeID[0] holds 1st set of Node ID
NodeID[1] holds 2nd set of Node ID

SlotID

U16*

Number Unit

Slot ID

Center_X

I32

Number of

pulses

Center X-coordinate on specified axis

Center_Y I32

Number of

pulses

Center Y-coordinate on specified axis

spiral_interval

I32

Number of

pulses

Relative distance between spirals

spiral_angle I32 Number

Total angle of spiral motion (one revolution is
360 degrees)

StrVel

I32

Pulses per

second

Starting velocity parameter

MaxVel I32

Pulses per

second

Tangential velocity parameter

Tacc

F64

Second

Specified acceleration time

Tdec

F64

Second

Specified deceleration time

m_curve

U16

Selection

1: T-curve
2: S-curve

m_r_a U16

Selection

0: Relative motion displacement
1: Absolute motion displacement
