Chapter 30 4-Channel Analog Input Remote I/O Module API | PCI-DMC-A01 / PCI-DMC-B01
30-8 Revised March, 2012
30.7 _DMC_01_set_04ad_conversion_time
 FORMAT
I16 _DMC_01_set_04ad_conversion_time (U16 CardNo, U16 NodeID, U16 SlotID,
U16 mode)

Purpose
Sets AD conversion time.

Parameters
Name
Data
Type
Unit Description
CardNo U16 Number Unit CardNo is between 0~15
NodeID U16 Number Unit Node ID is (0~12)
SlotID U16 Number Unit 0
Mode U16 Selection
Input value is 0 ~ 6
Number
Output
frequency
(Hz)
-3 dB
frequency
(Hz)
RMS noise
(µv)
0 372 200 9.6
1
1001 520 15.5
2 2005 1040 22.7
3
2534 1300 26.1
4 4826 2500 39.2
5 6041 3100 46.0
6 12166 6300 120.0

Example
U16 CardNo = 0;
U16 NodeID = 1;
U16 SlotID = 0;
U16 mode = 1;
I16 status = _DMC_01_set_04ad_conversion_time (CardNo, NodeID, SlotID, mode);
