Chapter 9 Point to Point Motion Control Packet Protocol API | PCI-DMC-A01 / PCI-DMC-B01

9-4

Revised March, 2012

9.3 _DMC_01_start_sdo_driver_a_move

FORMAT

I16 PASCAL _DMC_01_start_sdo_driver_a_move (I16 CardNo, U16 NodeID, U16 SlotID,
I32 Position)


Purpose

Starts absolute motion displacement.


Parameters

Name

Data Type

Unit

Description

CardNo U16 Number

Unit

CardNo is between 0~15

NodeID

U16

Number Unit

Node ID

SlotID

U16

Number Unit

Slot ID

Position

I32

Number of pulses

Absolute motion position


Example

U16 CardNo=0;
U16 NodeID =1;
U16 SlotID = 0; //If Slot ID is set to 0, then the Slave is a servo drive
I32 Position =10000000;
I16 status= _DMC_01_start_sdo_driver_a_move (CardNo, NodeID, SlotID, Position);
